1 Spray Distance： 200m
2 Rated Power： 220kw
3 Fan Motor ： 4Poles-185kw
4 Electronic ： Siemens PLC+Remote Control Schneider*ABB
5 Water Pump： 30Kw CNP Brand,China
6 Water Consumption： 20~40m³/h
7 Spray Head ： SS 304
8 Package Dimension ： L4200*W2300*H2500mm
9 Gross Weight ： 4500Kgs
Specification ：
| No | Item | Technical Parameter | Remark |
| 1 | Spray Distance | 200m | |
| 2 | Rated Power | 220kw | |
| 3 | Fan Motor | 4Poles-185kw | Hengli Brand |
| 4 | Motor Degree | IP55 | |
| 5 | Fan Drum mm | 1700mm | |
| 6 | Control Cabinet | Double Layer Carbon Steel | |
| 7 | Electronic | Siemens PLC+Remote Control | Schneider*ABB |
| 8 | Water Pump | 30Kw | CNP Brand,China |
| 9 | Water Consumption | 20~40m³/h | |
| 10 | Droplet Size | 50-300μm | |
| 11 | UP&Down | Hydraulic Road | |
| 12 | Protection | Limit+Over Load+Water pump protection | |
| 13 | Left&Right | Hydraulic | Gear Motor |
| 14 | Fan Blade | Alu Alloy | |
| 15 | Control | On-site +100 m remote control | |
| 16 | Pitching Angle | -5--+30℃ | |
| 17 | Left*Right Angle | 0-320℃ | |
| 18 | Spray Head | SS 304 Spray Nozzles, Total :180Pieces | |
| 19 | Thermal Protection | With Electric Heating | Optional |
| 20 | Package Dimension | L4000*W2300*H2500mm | |
| 21 | Gross Weight | 4500Kgs | |
| 22 | Appearance | Powder Painting | As Per Client |
| 23 | Water Supply | 4inch Pipeline,clean water 0.3Mpa～0.5Mpa |
